Evaluating Australian Challenge Corrosion Inhibitor Film

Background: Hiro Tatejima/Itochu Plastics System Co. submitted green LDPE co-extruded film labeled as Australian Challenge to Cortec Corporation for Corrosion inhibitor performance evaluation. Film claimed to contain VCIs.

Purpose: Evaluate corrosion inhibitor performance of film, labeled as Australian Challenge.

Method: Razor Blade Test

VIA Test

SO2 Test

Materials: Razor Blade Test Kit

VIA Test Kit

SO2 Test Kit

Procedure: The above tests were performed according to standard procedures for each.

Results: Razor Blade Test

Material

Panel #1

Panel #2

Panel #3

Australian Challenge Film

Fail

Fail

Fail

Cor-Pak Stretch Film*

Pass

Pass

Pass

Control

Fail

Fail

Fail

VIA Test

Material

Plug #1

Plug #2

Plug #3

Australian Challenge Film

Grade 0

Grade 0

Grade 0

Control

Grade 0

Grade 0

Grade 0

SO2 Test

Material

Panel #1

Panel #2

Panel #3

Australian Challenge Film

Grade 0

Grade 0

Grade 0

Cor-Pak Stretch Film*

Grade 4

Grade 4

Grade 4

Control

Fail

Fail

Fail

*Typical results of Cor-Pak Stretch Film

VIA Test Grades (Grade 2 or 3 are passing)





SO2 Grades (Grade 3 and 4 are passing):

Grade 0- Extensive corrosion covering 25% or more of panel surface

Grade 1- Moderate corrosion covering 10-25% of panel surface

Grade 2- Slight corrosion covering 5-10% of panel surface

Grade 3- Very slight corrosion covering 0-5% of panel surface

Grade 4- No visible corrosion on panel surface

Conclusion: The film labeled as Australian Challenge does not contain Cortec’s masterbatch, has not sufficient amount of inhibitors (if any), and, based on the testing results, doesn’t provide any corrosion protection.

Project #: 02-129-1125

Estimated Cost of Project: 2 hours

To: Hiro TateJima/Itochu Plastics System Co.

From: Bob Berg

Date: 6/13/02

cc: Boris Miksic

Anna Vignetti

Art Ahlbrecht

Margarita Kharshan

Cliff Cracauer

Bob Boyle

Vanessa Schultz
